ZOLL ECG Integration

How do I attach a ZOLL ECG to the Pulsara patient channel?

Note: The ZOLL ECG Integration will need to be enabled by one of our system administrators. Please reach out to your Pulsara Client Services Team for assistance or email us at help@pulsara.com. This feature is available with Pulsara version 10.3 or higher and is presently compatible with ZOLL X-Series monitors.

If you are a Pulsara EMS user, you can preconfigure the monitor assigned to your unit when you log in to the Pulsara app. Here is an example of how to do that...

Log In EMS Shift and Select Monitor





The following steps outline the process of attaching a ZOLL ECG (see animation below for example):

  • Once ECG is captured on X-Series Device, press the "Envelope" button on the left hand side of the monitor.  Next select the distribution list and press "Transmit":

Zoll Upload_1

  • Once complete, "Transmission complete" will be displayed on the monitor screen:
    zoll_2
  • From the Pulsara patient screen, tap the "ECGs" button. Multiple ECGs may be attached to a single event at one time or at different times.
  • Choose between “Monitor” for attaching a ZOLL ECG  or “Camera” to snap a photo of an ECG printout with your device's camera.
  • If “Monitor” is selected and Shift has been previously set up, monitor events that meet the set criteria will automatically appear.

NOTE: Changing the following criteria will update the query and could yield different results:

  • Transmitted Within” time window is defaulted to 30 minutes, but can be updated to search the last 1 hour, or the last 2 hours. The goal is to only show the most recent event for that monitor so that the User doesn’t have to scroll through several monitor events prior to attaching, but it’s flexible enough that you can search a larger window if necessary.
  • The “Monitor Device” field can be updated here to reflect a different Zoll X-Series device if necessary (something has changed from what was originally set up in the EMS Shift, or nothing is set up in the EMS shift). NOTE: Changing the value here does not currently update the Shift Setup Screen.
    • You may wish to change the monitor here if, for instance, you are now in the ER doing a bedside 12-Lead ECG with another Zoll X-Series monitor.
  • Validate that you have the correct ECG for the right patient
    • Patient ID - ID provided by the X-Series and can be used as a reference
    • Name - If entered into the X-Series, the First and Last Name will show up here
    • Date of Birth - If entered into the X-Series, Date of Birth will show up here
    • Acquired At - Is the Date and Time the device acquired the 12 Lead ECG. This provides a good time reference in relation to the Patient’s event for matching purposes
    • Received At - Is a Date and Time the ZOLL Cloud received the 12 Lead ECG. This is the specific time that we are using to query the “Transmitted Within” time window and is the primary field in relation to the Patient’s event for matching purposes
    • The 12 Lead image - Pressing on the image allows you to zoom in and out helping to further validate you are associating the correct ECG.
  • Attach - Attaching the ECG is the final step. Tap the "Attach" button. When complete, a numbered badge will show up on the ECGs button identifying the total of ECGs attached to the case.

Add Zoll ECGs-1

Alerting:

  • New patient - No ECG alerts are sent when added to a New patient. The team will receive the ECG once the primary alert is sent.
  • Existing and Recently stopped Patient - Secondary alerts will be sent when attaching an ECG.



There you have it — our ZOLL ECG integration feature in a nutshell! If you have additional questions on attaching ECGs, please contact your organization's Pulsara Administrator, or reach out to your Pulsara Client Services Team at www.pulsara.com/help.
